Wire Clamp Dimensions

Bolt Style Wire Clamps for Solid Wire Controls

The best for less!

  • Many applications: carb heat, cabin air, defrost control, oxygen control and more
  • Unique design to reduce wire stress
  • Heat treated stainless steel for wear and corrosion resistance
Part Number A Bolt Dia (in) B Wrench Size (in) C Thick (in) D Grip Length (in) E Hole Position (in) F Shank Length (in) G Hole Dia. (in) T Thread Application
MCS2323-1 0.188 8-Mar 0.125 0.25 0.183 0.653 0.073 Oct-32 carb heat, starter, mixture,
cabin heat, fuel shutoff, strainer drain, defrost, shutter, wastegate, oxygen
control, de-ice, heater, airbox, alternate air, flap/elevator, pressure air
dump, heat exchanger
MCS2323-2 0.25 16-Jul 0.156 0.312 0.325 0.781 0.073 1/4/2028 cabin heat, mixture, defrost,
cabin heat
MCS2323-3 0.25 16-Jul 0.156 0.188 0.199 0.539 0.073 1/4/2028 strainer drain, cowl flaps, carb
heat, alternate air
MCS2323-4 0.25 16-Jul 0.156 0.313 0.312 0.781 0.073 1/4/2028 mixture, flap indicator, flap
guide, fuel shut-off
MCS2323-5 0.188 8-Mar 0.125 0.125 0.188 0.531 0.073 Oct-32 cabin air, carb heat, starter,
airbox, defrost, flap, shutter, oxygen
MCS2323-6 0.25 16-Jul 0.156 0.188 0.355 0.656 0.073 1/4/2028 mixture, hopper, induction
MCS2323-7 0.188 8-Mar 0.125 0.25 0.192 0.656 0.076 Oct-32 fuel shut-off, alternate air,
flap elevator trim
MCS2323-8 0.188 8-Mar 0.125 0.25 0.202 0.656 0.096 Oct-32 fuel shut-off oxygen control
MCS2323-9 0.25 16-Jul 0.156 0.438 0.343 0.906 0.129 1/4/2028 flap control, flap guide
MCS2323-10 0.188 8-Mar 0.125 0.125 0.204 0.477 0.079 Oct-32 fuel shut-off, heat exchanger
MCS2323-11 0.188 8-Mar 0.125 0.25 0.266 0.656 0.076 Oct-32 mixture, bleed air, fuel
selector, flap/elevator
MCS2323-12 0.25 16-Jul 0.156 0.188 0.357 0.656 0.073 1/4/2028 mixture, cabin heat,
pressurization
MCS2323-13 0.25 16-Jul 0.156 0.313 0.271 0.781 0.073 1/4/2028 mixture, alternate air, bleed
air
MCS2323-14 0.188 8-Mar 0.125 0.125 0.132 0.531 0.082 Oct-32 cabin heat, cabin air
MCS2323-19 0.188 8-Mar 0.125 0.125 0.2 0.531 0.094 Oct-32 defroster
